D30 Flexible RTK Agricultural Base Station

Flexible Deployment, Precision Agriculture

How Can
We Help You?

Choose the option that fits your needs. We're here to help.

Get a Quote Product Inquiry Technical Support

Product Inquiry

The D30 is a flexible GNSS RTK receiver that can be used as a radio base station or CORS base station. It supports 4G, Ethernet, and radio communication. Users can flexibly configure solar panels, batteries, brackets, and power supply solutions based on site requirements. Compared with integrated solutions, the D30 is more suitable for agricultural customers who need flexible deployment, cost control, and project-based RTK network expansion.

SPECIFICATIONS

Signal Tracking

BDS: B1I, B2I, B3I, B1C, B2a

GPS: L1C/A, L2C, L2P(Y), L5

GLONASS: G1, G2

Galileo E1, E5a, E5b

QZSS L1C/A, L2C, L5

SBAS L1C/A

Interface

LoRa: 1 TNC interface, optional

Data and power interface: 1 7-core LEMO interface (RS232+power), supporting external sensors

Card slot: 1 Nano SIM card slot, 1 SD card slot

Ethernet: RJ45 (optional)

Accuracy and Reliability

Static Solution: Horizontal ±(2.5 + 0.5 × 10⁻⁶D) mm, Vertical (5.0 + 0.5 × 10⁻⁶D) mm

Dynamic Solution: Horizontal ±(8 + 1 × 10⁻⁶D) mm, Vertical ±(15 + 1 × 10⁻⁶D) mm

RTK Accuracy: Horizontal ±8mm + 1ppm, Vertical ±15mm + 1ppm

First Positioning Time: Cold Start < 60s, Warm Start < 15s

RTK Initialization Time: <10s, baseline length less than 10 km

Initialization Reliability: >99.9%

Electrical Specifications

Power supply: DC 9–36V, supports reverse connection protection, built-in photoelectric isolation

Power consumption: Typical 1.5W, 0.8W in low-power mode

Indicator light: 1 power light, 1 4G light, 1 differential light

Storage Function

Supports external SD card expansion (up to 32 GB)

Storage Format: RTCM, NMEA 0183

Storage Method: Cyclic storage supported

Environmental Characteristics

Working temperature: -40°C ~ +75°C

Storage temperature: -55°C ~ +85°C

Waterproof and dustproof: IP67

Relative humidity: 100% non-condensing

Communication Configuration

Network Module: 4G full-network connectivity (5G optional)

LoRa Transceiver Frequency Band: 410-470 MHz

Ethernet: 10M / 100M

Data Format & Protocol

Supported Differential Formats: CMR, RTCM 2.X, RTCM 3.X

Network: TCP, MQTT, Ntrip

Serial port: RS232 protocol

Stable and Reliable

Miniaturized Deployment | All-Weather Survival

Minimal body, plug-and-play quick deployment

IP67 protection, shock certified

-45°C extreme cold start / +75°C high-temperature zero drift

Low power consumption / self-sufficient solar power supply
