N30 Integrated Power Supply GNSS Receiver

Integrated Deployment, Stable Long-Term Operation

The N30 integrates a GNSS receiver, solar panel, battery, and communication module for long-term outdoor GNSS applications. Its integrated structure reduces on-site installation complexity and is suitable for long-term unattended outdoor projects.

Get a Quote Specifications

How Can
We Help You?

Choose the option that fits your needs. We're here to help.

Get a Quote Product Inquiry Technical Support

Product Inquiry

The N30 integrates a GNSS receiver, solar panel, battery, and communication module for long-term outdoor GNSS applications. It supports 4G, NTRIP, and remote data management, and can be used for CORS base station and radio base station projects. Its integrated structure reduces on-site installation complexity and is suitable for long-term unattended outdoor projects.

SPECIFICATIONS

Signal Tracking

BDS: B1I, B2I, B3I, B1C, B2a

GPS: L1C/A, L2C, L2P(Y), L5

GLONASS: G1, G2

Galileo E1, E5a, E5b

QZSS L1C/A, L2C, L5

SBAS L1C/A

Environmental Characteristics

Operating temperature: -40°C to +75°C

Storage temperature: -55°C ~ +85°C

Waterproof and dustproof: IP67

Relative humidity: 100% non-condensing

Accuracy and Reliability

Static: Planar ±(2.5 + 0.5 × 10⁻⁶D) mm, Elevation (5.0 + 0.5 × 10⁻⁶D) mm

Dynamic: Planar ±(8 + 1 × 10⁻⁶D) mm, Elevation ±(15 + 1 × 10⁻⁶D) mm

RTK Accuracy: Horizontal ±8mm + 1ppm, Vertical ±15mm + 1ppm

First Positioning Time: Cold Start < 60s, Warm Start < 15s

RTK initialization time: <10s (baseline length less than 10km)

Initial confidence level: >99.9%

Communication Protocol

Network: TCP, MQTT, Ntrip

Serial Port: RS232 Protocol

Electrical Specifications

Power Supply: DC 9–36V, supports reverse polarity protection, built-in optical isolation

Indicator Lights: 1 Power, 1 4G, 1 Differential, 1 Bluetooth, 1 TF

Battery Heating Film: 15 W (optional)

Built-in battery capacity: 128,000 mAh

Solar panel: 20W

Data Format

Differential Format Support: CMR, RTCM 2.X, RTCM 3.X

Communication Configuration

Network Module: 4G full-network connectivity

LoRa Transceiver Frequency Band: 410MHz – 470MHz

Bluetooth: Optional

Storage Function & Interface

Storage: Supports external SD card expansion (up to 32 GB)

Storage Format: RTCM, NMEA-0813

Card slots: 1 Nano SIM card slot, 1 SD card slot

Switch: A self-locking switch

High-Precision GNSS Support

Integrated Deployment for Long-Term Stable Operation

Highly integrated solar + battery power system

Remote connectivity via 4G & NTRIP

Long-term, unattended outdoor applications

128,000 mAh battery with 20W solar panel
